DIN 906 Hexagon Socket Pipe Plug
Material
Surface Treatment

A.Carbon Steel

B.Stainless Steel

C.Brass

D.Aluminium

E.Alloy Steel


A.Plain oiled

B.Zinc Plated

C.Phosphotized

D.Black oxidized

E.Zn-Ni Alloy Plated


T

S

H

L

Wt.

mm

inch

mm

mm

mm

g

M8X1

-

-

4

4.7

8

2.07

M10X1

-

R1/8

5

4.7

8

3.38

M12X1.5

-

-

6

5.9

10

6.1

-

-

R1/4

7

6

10

7

M14X1.5

-

-

7

6

10

8.1

M16X1.5

-

-

8

6.2

10

11.1

-

-

R3/8

8

6.2

10

12.2

M18X1.5

-

-

8

6.2

10

14.6

M20X1.5

-

-

10

6.4

10

17.6

-

-

R1/2

10

6.4

10

19

M22X1.5

-

-

10

6.4

10

22

M24X1.5

-

-

12

7.7

12

30.8

M26X1.5

-

-

12

7.7

12

38.6

-

M27X2

R3/4

12

7.7

12

40.2

M30X1.5

M30X2

-

17

7.7

12

44

-

M33X2

R1

17

7.7

12

57.5

M36X1.5

M36X2

-

19

9.2

15

85.2

M38X1.5

-

-

19

9.2

15

94.4

-

M39X2

-

19

9.2

15

103

M42X1.5

M42X2

R1 1/4

22

13.3

18

135

M45X1.5

M45X2

-

22

13.3

18

167

M48X1.5

M48X2

R1 1/2

24

13.5

20

214

M52X1.5

M52X2

-

24

13.5

20

253

-

M56X2

-

32

15.6

22

274

-

M60X2

-

32

15.6

22

350
